Features:
1. One machine for different business line. It can use eco solvent ink for bill board advertisment, can use sublimation ink for textile industry, and also can use water-based ink for photo imaging industry.
2.Maintop5.3 software is used. Adopt high speed board, cartridge high speed moving and zero paper skip waiting time, improve the speed to a extreme standard.
3.Equipment with auto ink sucking device , enables a more convenient and faster printhead maintenance.
|
Product Model
|
Special-A3350 ,
|
|
Printing Technology
|
Epson 7th Micro Piezo printhead Technology
|
|
Number of Printhead
|
2 Heads / 2880 Nozzles OR 1head/1440 Nozzle
|
|
Ink Colors
|
4 colors / (C,M,Y,K)
|
|
Printhead Height
|
Adjustable 2~5mm
|
|
Resolution
|
2880DPI or 1440DPI
|
|
Ink Droplet Size
|
1.5~21pl
|
|
Printing Width
|
3200mm(max)
|
|
Speed
|
High Speed Mode: 720 x 720dpi 30㎡/h 75 ㎡/h
|
|
Standard Mode: 720 x 1080dpi 18 ㎡/h 30㎡/h
|
|
Photo Mode: 720 x 1440dpi 15 ㎡/h 18㎡/h
|
|
Heating System
|
The heaters for front , center and behind
|
|
Media
|
Width(max):3200mm
|
|
Media feeding mode: Automatic feeder
|
|
Automatic take up (optional)
|
|
Self-adhesive paper, PVC, Mesh fabric, Textile, PVC flex banner, Vinyl, Paper, Fabric, Leather etc.
|
|
Ink
|
ECO Solvent Ink
|
|
ECO Solvent Dye Ink
|
|
Water Based Dye Ink
|
|
Ink Supply
|
Pipe based continues ink supply / Ink Cartridge 800ml
|
|
RIP Software
|
Maintop5.3
|
|
Photoprint (option)
|
|
Printing Interface
|
USD2.0
|
|
Operating System
|
Windows XP
|
|
Voltage
|
50/60HZ ,220V 10A
|
|
Machine Dimension
|
Special-A3350:L4250mm x W700mm x H1270mm
|
|
Package Dimension
|
Special-A3350:L4300mm x W760mm x H650mm
|
|
Working Environment
|
Temperature 10°C~30°C Humidity 40~70% Non-condensing
|
